TYPICAL SPECIFICATION
Download Full Catalog| 技术指标 | 产品参数 |
|---|---|
| 检测原理 | 激光散射 |
| 检测范围 | 0μg/m³~1000μg/m³ |
| 最低检出粒子直径 | 0.3μm |
| 分辨率 | 1μg/m³ |
| 检测精度 | 0μg/m³-100μg/m³：±20μg/m³ 100μg/m³-1000μg/m³：±20% |
| 开机稳定时间 | ≤6s |
| 工作温度 | -20-70℃ |
| 工作湿度 | 5-95%RH（非凝结） |
| 储存温度 | -40-80℃ |
| 工作电压 | 12V（9-16V） |
| 工作电流 | ≤150mA |
| 防护等级 | IP5X |
| 额定功率 | ≤2.5W |
| 噪音 | ＜30dB（A） |
| 通讯协议 | LIN |
| 设计寿命 | 20万公里或5年 |
