Indoor Paritulate Matter Sensor

Indoor Paritulate Matter Sensor
Sunny H8300B Particulate Matter Sensor is a laser-based sensor which detects and counts particles using light scattering. The mass concentration range is 0 μg/m³ to 1,000 μg/m³. It will enable the implementation of innovative air quality monitoring devices that prevent air pollution damage.

Applications

· Fresh Air Ventilation System ·
· Smart Home Control Panel ·
· Air Purifier ·
· Air Quality Monitor ·

Features

Ultra-slim | Thickness: 12 mm Easy to integrate into a variety of devices
Fast | Response time: ≤ 5 s Using high-speed chips,makes data processing faster
Precise | Mass concentration precision: ±10% The unique air duct design makes it difficult to accumulate dust inside the product
Quiet | Noise: ≤ 30 dB(A) Using the cycle seal bearning ensures the fan reamins long term stability and low noise

Specifications

Operating principle Laser scattering
Lower limit of detection 0.3 μm
Mass concentration range 0 μg/m³ to 1,000 μg/m³
Mass concentration resolution 1 μg/m³
Mass concentration accuracy ±10 μg/m³ @ 0 μg/m³ to 100 μg/m³
±10% @ 101 μg/m³ to 1,000 μg/m³
Response time ≤ 5 s
Operating temperature range -10 ℃ to +50 ℃
Operating humidity Levels 5% RH to 95% RH
Storage temperature range -20 ℃ to +60 ℃
Storage humidity Levels 0% RH to 95% RH (non-condensing)
Supply voltage DC 5 V ±0.1 V
Working current ≤ 100 mA
Standby current ≤ 20 mA
Lifetime > 3 years
Interface UART
Dimensions (W * H * D ) 48 mm * 40 mm * 12 mm
Please refer to the sensor specification
